Additional information
| Weight | 2,014 kg |
|---|---|
| Reference number | 1506226, 8285260000, 303352, 12E0308826AA, 1935103, S054716, 54716, 054716 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation angle | -40° to 33° |
| Break point | 7.3 psi |
| Calculated Volume (dm³) | 4.7938 |
| Comments | With lever and tension spring (range of adjustment: 10mm to 20mm) |
| Distance between bolts | 3.31×3.31 in |
| Exhaust | Flap |
| Important information | If you need to calibrate this Load Sensing Valve, please use our LSV-Calculator (<a href="https://www.wabco-customercentre.com/solutioncentre/s/article/Diagnostics-resource-centre?language=en_US" target="_blank">Click here</a> ) |
| Max. operating pressure | 145.0 psi |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | 2x M16 x 1.5 |
| Port thread 4 | M22 x 1.5 |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Mechanical |
| GTIN | 04057875225874 |
| Size (mm x mm x mm) | 321 x 131 x 114 |
| UPC | 193133315148 |
| Weight (kg) | 2.014 |
| Weight (lb) | 4.4401 |
| Type of operation | Static |
| Brand | WABCO |
