Additional information
| Weight | 0,9 kg |
|---|---|
| Reference number | 86524 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation | Electrical |
| Calculated Volume (dm³) | 1.53 |
| Electrical connection | DIN 72585-A1-3.6-Sn/K1 |
| Max. operating pressure | 188.5 psi |
| Port thread 11 | Ø 12 x 1.5 |
| Port thread 12 | Ø 8 x 1 |
| Port thread 21 | 2x Ø 8 x 1 |
| Port thread 22 | 2x Ø 8 x 1 |
| Port thread 31 | Flap Exhaust |
| Protection class | IP 6K9K |
| Rated current | 220 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Type | LACV |
| Version | Single-circuit |
| Voltage | 24 V |
| Size (mm x mm x mm) | 70 x 115 x 190 |
| UPC | 193133307297 |
| Weight (kg) | 0.9 |
| Weight (lb) | 1.9842 |
| GTIN | 04057875213772 |
| Brand | WABCO |
