Additional information
| Weight | 2,2 kg |
|---|---|
| Reference number | 1506108, 005987, MO59098, 3766-014, 4630840200, 6BV00270300, 500433769, 1133003, 58104011, 5810401, 5058104011, 505810401, 8285541000, 1111152, 910015-00049, 3311337, 095515, 1506108, 4425014100, 1912362, 051229, 8285541000, 51229, 36512, A8188-011100, T852-068, 10595066, WA4630840200, 1013159 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation | Automatic |
| Application | Trailer |
| Bolt lengths | 0.47 in |
| Calculated Volume (dm³) | 2.6376 |
| Max. operating pressure | 188.5 psi |
| Port thread 1 | M16 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 23 | M16 x 1.5 |
| Port thread 24 | M16 x 1.5 |
| Port thread 3 | Flap Exhaust |
| Port thread 41 | M16 x 1.5 |
| Port thread 42 | Test port |
| Range of adjustment | 29.01 to 101.53 psi |
| Switch pressure | Lowering: 65.27 / Lifting: 36.26 psi |
| Temperature range | -40°C to +80°C |
| Type | LACV |
| Version | Dual-circuit |
| GTIN | 04057875213765 |
| Size (mm x mm x mm) | 148.5 x 166 x 110 |
| UPC | 193133305903 |
| Weight (kg) | 2.2 |
| Weight (lb) | 4.8502 |
| Technical specification | OE specification |
| Brand | WABCO |
