Additional information
| Weight | 2,028 kg |
|---|---|
| Reference number | 515015180, 6503129, 1272953, 6281011, 2090295, 1105018, 86427, 20199001562, 11183064 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation | Electrical |
| Application | T EBS, ECAS, Immobilizer |
| Calculated Volume (dm³) | 2.703 |
| Electrical connection | DIN 72585-A1-4.2-Sn/K2 |
| Max. operating pressure | 188.5 psi |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | M22 x 1.5 |
| Port thread 22 | M22 x 1.5 |
| Port thread 23 | M22 x 1.5 |
| Port thread 24 | M22 x 1.5 |
| Port thread 25 | M22 x 1.5 |
| Port thread 31 | M22 x 1.5 |
| Port thread 32 | Silencer 432 407 060 0 |
| Protection class | IP6K6K |
| Rated current | 340 mA |
| Technical specification | OE specification |
| Type | LACV-IC |
| Version | Dual-circuit |
| Voltage | 24 V |
| GTIN | 04057875213802 |
| Size (mm x mm x mm) | 210 x 66 x 195 |
| UPC | 193133307426 |
| Weight (kg) | 2.028 |
| Weight (lb) | 4.471 |
| Temperature range | -40°C to +65°C |
| Brand | WABCO |
