Additional information
| Weight | 2,2 kg |
|---|---|
| Reference number | 867872, 0867872, 01162, 6114, 061847, MO58229, 163321, 4630840000, 1133002, S4630840000, 21153104010, 1111150, 6280101, 8235-S4630840000, ZG046200002, S4630840000, 1075359, 201658, M058229, 0867872, S4630840000, 4425013800, 1738469, 50951, 050951, 21153104010, 10582267, WA4630840000, 1013153 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation | Manual |
| Application | Trailer |
| Bolt lengths | 0.47 in |
| Calculated Volume (dm³) | 0 |
| Max. operating pressure | 188.5 psi |
| Port thread 1 | M16 x 1.5 |
| Port thread 2 | M22 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 23 | M16 x 1.5 |
| Port thread 24 | M16 x 1.5 |
| Port thread 3 | Flap Exhaust |
| Port thread 41 | M16 x 1.5 |
| Port thread 42 | Test port |
| Range of adjustment | 29.01 to 101.53 psi |
| Switch pressure | 58.02 psi |
| Temperature range | -40°C to +80°C |
| Type | LACV |
| Version | Dual-circuit |
| GTIN | 04057875213673 |
| Size (mm x mm x mm) | 139 x 166 x 107.5 |
| UPC | 193133442493 |
| Weight (kg) | 2.2 |
| Weight (lb) | 4.85 |
| Technical specification | OE specification |
| Brand | WABCO |
