Additional information
| Weight | 0,331 kg |
|---|---|
| Reference number | 1518858, 99433854, 99433854, 2V2412259, 2V2412259 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation | Ø 6 x 13.31 in |
| Actuation Angle | 90° |
| Calculated Volume (dm³) | 0.92018 |
| Distance between holes | 1.97/1.57 in |
| Height | No hight limitation |
| Max. operating pressure | 188.5 psi |
| Mounting | 4x Ø 8.8 mm |
| Multi Nominal diameter (From Port 1 to x) | 0.12 in |
| Port thread 1 | M12 x 1.5 |
| Port thread 21 | M12 x 1.5 |
| Port thread 22 | M12 x 1.5 |
| Port thread 3 | Silencer |
| Side of mounting | 4-sided |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 2-circuit |
| GTIN | 7895851059177 |
| Size (mm x mm x mm) | 67 x 126 x 109 |
| UPC | 193133308225 |
| Weight (kg) | 0.331 |
| Weight (lb) | 0.72973 |
| Version | With Lever |
| Brand | WABCO |
