Additional information
| Weight | 0,524 kg |
|---|---|
| Reference number | 1518859, 1738474, 1103985 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation angle | 90° |
| Body material | Aluminium |
| Calculated Volume (dm³) | 2.6719 |
| Comments | 2-circuit. Same as 4640061000, but black |
| Distance between holes | 1.57/1.97 in |
| Max. operating pressure | 188.5 psi |
| Mounting | 4x Ø 8.8 mm |
| Nominal diameter | 3.0 mm |
| Port thread 1 | M12 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port thread 21 | M12 x 1.5 |
| Port thread 22 | M12 x 1.5 |
| Port thread 23 | M16 x 1.5 |
| Port thread 3 | Flap Exhaust |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Version | With Lever |
| GTIN | 04057875214823 |
| Size (mm x mm x mm) | 349 x 116 x 66 |
| UPC | 193133308348 |
| Weight (kg) | 0.524 |
| Weight (lb) | 1.1552 |
| Type | 2-stage with regulation |
| Brand | WABCO |
