Additional information
| Weight | 0,399 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation angle | 90° |
| Body material | Composite |
| Calculated Volume (dm³) | 5.799 |
| Comments | 2-circuit. Rod mounted from right hand |
| Distance between holes | 1.57/1.97 in |
| Max. operating pressure | 188.5 psi |
| Mounting | 4x Ø 8.8 mm |
| Nominal diameter | 3.0 mm |
| Port thread 1 | Ø 8 x 1 |
| Port thread 21 | Ø 8 x 1 |
| Port thread 22 | Ø 8 x 1 |
| Port thread 3 | Integrated Silencer |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 2-stage without regulation |
| Version | With Lever |
| Size (mm x mm x mm) | 135 x 120 x 358 |
| UPC | 193133406167 |
| Weight (kg) | 0.399 |
| Weight (lb) | 0.88 |
| GTIN | 04057875371724 |
| Brand | WABCO |
