Additional information
| Weight | 0,209 kg |
|---|---|
| Reference number | TDAS4640070040, S464-007-004-0, 8235-S4640070040, 6300-4640070040, QWABS4640070040, S4640070040, S464-007-004-0, MES4640070040, 85106009, WAB4640070040 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation angle | -19° to +19° |
| Calculated Volume (dm³) | 0.48608 |
| Distance between holes | 1.83 in |
| Length | R 201 mm |
| Max. operating pressure | 159.5 psi |
| Mounting | 2x Ø 8.5 mm |
| Port thread 1 | Quick Connection 1/4" |
| Port thread 2 | Quick Connection 1/4" |
| Stroke of lever | ±30° |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | With Lever |
| Type of operation | Hole-lever Ø 6.5 mm |
| Version | With one-way valve |
| GTIN | 04057875214939 |
| Size (mm x mm x mm) | 224 x 62 x 35 |
| Weight (kg) | 0.209 |
| Weight (lb) | 0.46077 |
| UPC | 193133442677 |
| Brand | WABCO |
