Additional information
| Weight | 0,255 kg |
|---|---|
| Reference number | 0005661838, 5010260136, 7420746465, 20746465, 7420746465 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Actuation angle | -19° to +19° |
| Body material | Plastic |
| Calculated Volume (dm³) | 0.8269 |
| Distance between holes | 1.83 in |
| Fixing length (body + lever) | 5.79 in |
| Length | R 171 mm |
| Max. operating pressure | 159.5 psi |
| Mounting | 2x Ø 8.5 mm |
| Port thread 1 | Quick Connection Ø 0.24 in |
| Port thread 2 | Quick Connection Ø 0.24 in |
| Ports | Push in fitting Ø 6 |
| ProVia warranty | 1 year |
| Technical specification | AM specification |
| Temperature range | -40°C to +80°C |
| Type | With Lever |
| Type of lever fixing | 3 fixing holes |
| Version | With one-way valve |
| GTIN | 04057877003197 |
| Size (mm x mm x mm) | 245 x 75 x 45 |
| UPC | 193134004348 |
| Weight (kg) | 0.255 |
| Weight (lb) | 0.5622 |
| Type of operation | Hole-lever Ø 6.5 mm |
| Brand | WABCO |
