Additional information
| Weight | 0,826 kg |
|---|---|
| Reference number | 2089980 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Actuation angle | 90° |
| Calculated Volume (dm³) | 5.358 |
| Distance between holes | 1.57/1.97 in |
| Max. operating pressure | 188.55 psi |
| Mounting | 4x Ø 8.8 mm |
| Nominal diameter | 3.0 mm |
| Port thread 1 | M12 x 1.5 |
| Port thread 12 | M12 x 1.5 |
| Port thread 21 | M12 x 1.5 |
| Port thread 22 | M12 x 1.5 |
| Port thread 23 | M12 x 1.5 |
| Port thread 3 | Flap Exhaust |
| ProVia warranty | 1 year |
| Push-in fitting | Ø 8×1.0 |
| Technical specification | AM specification |
| Temperature range | -40°C to +80°C |
| Variant | Height limitation |
| Version | With Lever |
| GTIN | 04057877004934 |
| Size (mm x mm x mm) | 363 x 120 x 123 |
| UPC | 193134001507 |
| Weight (kg) | 0.826 |
| Weight (lb) | 1.821 |
| Type | 2-stage with regulation |
| Brand | WABCO |
