Additional information
| Weight | 0,626 kg |
|---|---|
| Reference number | F005268, 243113500, EXABRB613, 1325336, 1518859, 1260680, 8285499000, 3852, 071432, XCT2K432AA, CF352131, F005268, 162347, 464/006/100/0, 4640061000, IT4352, 2129007, 2129002, 505808613, 5058086130, 58086130, 21151103151, 8285499000, 82854990000, 318955, 3189550, 1111173, 4110261, EXABRB613, EXABRB613, 503200001, A05021256, 5661833, 0005661833, 1260680, 538109X500, 3323119, 0568615, 495040, 49500451003, F005268, CV118427, 4425013400, 1738474, 2089978, 050637, 1103985, 82854990000, 27475, 21151103151, 637213050, 1013140 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Actuation angle | 90° |
| Calculated Volume (dm³) | 3.15 |
| Distance between holes | 1.57/1.97 in |
| Max. operating pressure | 188.55 psi |
| Mounting | 4x Ø 8.8 mm |
| Nominal diameter | 3.0 mm |
| Port thread 1 | M12 x 1.5 |
| Port thread 12 | M12 x 1.5 |
| Port thread 21 | M12 x 1.5 |
| Port thread 22 | M12 x 1.5 |
| Port thread 23 | M12 x 1.5 |
| Port thread 3 | Flap Exhaust |
| ProVia warranty | 1 year |
| Technical specification | AM specification |
| Temperature range | -40°C to +80°C |
| Type | 2-stage with regulation |
| Version | With Lever |
| GTIN | 04057877003807 |
| Size (mm x mm x mm) | 360 x 125 x 70 |
| UPC | 193134001408 |
| Weight (kg) | 0.626 |
| Weight (lb) | 1.38 |
| Variant | Height limitation |
| Brand | WABCO |
