Additional information
| Weight | 0,26 kg |
|---|---|
| Reference number | 2093357 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Actuation Angle | -19° to +19° |
| Body material | Plastic |
| Calculated Volume (dm³) | 0.8269 |
| Distance between holes | 1.83 in |
| Fixing length (body + lever) | 5.37 in |
| Length | R 160.5 mm |
| Max. operating pressure | 159.54 psi |
| Mounting | 2x Ø 8.5 mm |
| Port thread 1 | Raufoss ABC small cartridge external Ø 0.24 in |
| Port thread 2 | Raufoss ABC small cartridge external Ø 0.24 in |
| Ports | Raufoss ABC small cartridge external Ø 6mm |
| ProVia warranty | 1 year |
| Technical specification | AM specification |
| Temperature range | -40°C to +100°C |
| Type | With Lever |
| Type of operation | Hole-lever Ø 0.26 in |
| GTIN | 04057877026776 |
| Size (mm x mm x mm) | 245 x 45 x 75 |
| UPC | 193134008087 |
| Weight (kg) | 0.259 |
| Weight (lb) | 0.571 |
| Version | With one-way valve |
| Brand | WABCO |
