Additional information
| Weight | 0,538 kg |
|---|---|
| Reference number | 655687, F001572, 243109200, 1325337, 8143280, 4027060, 8283637000, 82836370000, 5139, 001797, 001846, 4C462K433AA, CF351950, F001572, CF351950/F001572, CF351950F001572, 157537, 464/006/002/0, 4640060020, 04853325, 4853325, IT4358, 9236180001, 2129005, 229600060, 500945035/1, 09450351, 5009450351, 945035, 9450351, 21151103150, 82836370000, 312470, 1111172, 4110201, 502918201, A05020507, A05020506, 5661808, 0005661808, 2TB412600A, 4027060, 81436106116, 81436106117, QWAB4640060020, 53810D9400, 309101, 0309101, 0568515, 495039, 49500451002, 5010260213, 04425010400, 0339792, 2089976, 339792, 055634, 050419, 50419, 730517, 82836370000, S050419, 21884, 21151103150, 53810D9400, 10505355, 2TB412600A, 1013120 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Actuation angle | 90° |
| Calculated Volume (dm³) | 3.15 |
| Distance between holes | 1.57/1.97 in |
| Max. operating pressure | 188.55 psi |
| Mounting | 4x Ø 8.8 mm |
| Nominal diameter | 3.0 mm |
| Port thread 1 | M12 x 1.5 |
| Port thread 21 | M12 x 1.5 |
| Port thread 22 | M12 x 1.5 |
| Port thread 3 | Flap Exhaust |
| ProVia warranty | 1 year |
| Technical specification | AM specification |
| Temperature range | -40°C to +80°C |
| Type | 2-stage without regulation |
| Variant | Basic |
| Version | With Lever |
| Size (mm x mm x mm) | 360 x 125 x 70 |
| UPC | 193134001330 |
| Weight (kg) | 0.538 |
| Weight (lb) | 1.186 |
| GTIN | 04057877004927 |
| Brand | WABCO |
