Additional information
| Weight | 0,978 kg |
|---|---|
| Reference number | 1524321, 20367533 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Actuation angle | 59.5° |
| Calculated Volume (dm³) | 7.425 |
| Comments | Blocking valve / Left hand Drive |
| Exhaust | Hose Nozzle Ø 6.5 mm |
| Max. operating pressure | 123.28 psi |
| Mounting | 4x Ø 6.16 mm |
| Operating pressure | 85.6 psi |
| Port thread 1 | Ø 0.37 in |
| Port thread 21 | M5 |
| Port thread 22 | M5 |
| Ports | Dedicated connector |
| ProVia warranty | 1 year |
| Technical specification | AM specification |
| Temperature range | -40°C to +80°C |
| Type | Working Medium Air |
| GTIN | 04057877007713 |
| UPC | 193134006229 |
| Weight (kg) | 0.978 |
| Weight (lb) | 2.156 |
| Size (mm x mm x mm) | 250 x 180 x 165 |
| Brand | WABCO |
