Additional information
| Weight | 0,8 kg |
|---|---|
| Reference number | ABRH040 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation angle | 53° |
| Calculated Volume (dm³) | 2.542 |
| Color | Black/Black |
| Distance between holes | 3.15 in |
| Exhaust | Flap |
| Max. operating pressure | 145.04 psi |
| Mounting | 2x M6 |
| Port thread 1 | M16 x 1.5 JED – 464 |
| Port thread 21 | M16 x 1.5 JED – 464 |
| Port thread 22 | M16 x 1.5 JED – 464 |
| Rated current | 500 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 24 V |
| GTIN | 04057875328827 |
| Size (mm x mm x mm) | 200 x 82 x 155 |
| Weight (kg) | 0.8 |
| Weight (lb) | 1.7637 |
| UPC | 193133370857 |
| Brand | WABCO |
