Additional information
| Weight | 0,882 kg |
|---|---|
| Reference number | 1524294, 1524802, 08132394, 98405732, 8132394 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Actuation angle | 73° |
| Calculated Volume (dm³) | 2.2 |
| Comments | With electrical swich |
| Distance between holes | 3.15 in |
| Max. operating pressure | 159.5 psi |
| Mounting | 2x M8 |
| Operating pressure | 79.8 psi |
| Port thread 1 | M16 x 1.5 JED – 388 |
| Port thread 21 | M16 x 1.5 JED – 388 |
| Port thread 22 | M16 x 1.5 JED – 388 |
| Ports | M16 x 1.5 |
| ProVia warranty | 1 year |
| Technical specification | AM specification |
| Temperature range | -40°C to +80°C |
| Type | Working Medium Air |
| GTIN | 04057877007478 |
| UPC | 193134006281 |
| Weight (kg) | 0.882 |
| Weight (lb) | 1.944 |
| Size (mm x mm x mm) | 220 x 80 x 125 |
| Brand | WABCO |
