Additional information
| Weight | 0,769 kg |
|---|---|
| Reference number | BC452A622BBW, BC452A622BB3YYW, BC452A622BA |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation angle | 73° |
| Calculated Volume (dm³) | 1.5456 |
| Color | Black |
| Distance between holes | 3.15 in |
| Exhaust | Hose Nozzle Ø 6 mm |
| Max. operating pressure | 145.04 psi |
| Mounting | 2x Ø 9 mm |
| Port thread 1 | M16 x 1.5 JED – 464 |
| Port thread 21 | M16 x 1.5 JED – 464 |
| Port thread 22 | M16 x 1.5 JED – 464 |
| Rated current | 500 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 24 V |
| GTIN | 7895851066632 |
| Size (mm x mm x mm) | 230 x 105 x 64 |
| Weight (kg) | 0.769 |
| Weight (lb) | 1.6954 |
| UPC | 193133371083 |
| Brand | WABCO |
