Additional information
| Weight | 0,503 kg |
|---|---|
| Reference number | 1241246, 0290666, 290666, 5010119657, 41241246, 1241246 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation angle | 73° |
| Calculated Volume (dm³) | 1.2168 |
| Color | Black/Black |
| Comments | Vented |
| Distance between holes | 3.15 in |
| Exhaust | Hose Nozzle Ø 6 mm |
| Max. operating pressure | 145.04 psi |
| Mounting | M6 |
| Parking position | 73° |
| Port thread 1 | M16 x 1.5 JED – 464 |
| Port thread 21 | M16 x 1.5 JED – 464 |
| Port threads | M16 x 1.5 VOSS |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | vented |
| GTIN | 04057875297758 |
| UPC | 193133371144 |
| Weight (kg) | 0.503 |
| Weight (lb) | 1.11 |
| Size (mm x mm x mm) | 103 x 179 x 66 |
| Brand | WABCO |
