Additional information
| Weight | 0,792 kg |
|---|---|
| Reference number | 1518237, 81523156156, 81523156156, 81523156160, 81523156161, 81523159156, 64523156012, 81523156171, 81523156156, 1518237, 1935570 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation angle | 73° |
| Calculated Volume (dm³) | 1.4394 |
| Color | Black |
| Distance between holes | 3.54 in |
| Exhaust | Flap |
| Max. operating pressure | 145.04 psi |
| Mounting | 2x M8 |
| Port thread 1 | M16 x 1.5 JED – 388 |
| Port thread 21 | M16 x 1.5 JED – 388 |
| Port thread 22 | M16 x 1.5 JED – 388 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 7895851071919 |
| Size (mm x mm x mm) | 193 x 113 x 66 |
| UPC | 193133370581 |
| Weight (kg) | 0.792 |
| Weight (lb) | 1.7461 |
| Brand | WABCO |
