Additional information
| Weight | 0,81 kg |
|---|---|
| Reference number | 1518235, A0024307981, TDAS9617231040, S9617231040, 6300-9617231040, 0024307581, 0024307781, 0024307981, A0024307981, S9617231040, S9617231040, WAB9617231040 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation angle | 73° |
| Calculated Volume (dm³) | 1.338 |
| Color | Green-gray |
| Distance between holes | 3.54 in |
| Exhaust | Flap |
| Max. operating pressure | 145.04 psi |
| Mounting | M8 |
| Parking position | 73° |
| Port thread 1 | M16 x 1.5 JED – 388 |
| Port thread 21 | M16 x 1.5 JED – 388 |
| Port thread 22 | M16 x 1.5 JED – 388 |
| Port threads | M16 x 1.5 VOSS |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 7895851083295 |
| Size (mm x mm x mm) | 194. x 60.5 x 114 |
| Weight (kg) | 0.81 |
| Weight (lb) | 1.7857 |
| UPC | 193133449270 |
| Brand | WABCO |
