Additional information
| Weight | 0,644 kg |
|---|---|
| Reference number | 1518233, 81523159113, 81523156113, 81523156116, 81523156118, 81523159113, 81523156113 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation angle | 73° |
| Calculated Volume (dm³) | 1.9417 |
| Color | Black/Black |
| Distance between holes | 3.15 in |
| Exhaust | Hose Nozzle Ø 8.5 mm |
| Max. operating pressure | 145.04 psi |
| Mounting | Ø 6.5 |
| Parking position | 73° |
| Port thread 1 | M16 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port threads | M16 x 1.5 VOSS |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057875297208 |
| Size (mm x mm x mm) | 213 x 106 x 86 |
| Weight (kg) | 0.644 |
| Weight (lb) | 1.4198 |
| UPC | 193133449256 |
| Brand | WABCO |
