Additional information
| Weight | 0,5 kg |
|---|---|
| Reference number | 1519261, 4429003111, 5000452903, 0300379200, 503135543, 5000452903, 4429003111, E4429003111, 5000452903, 1102307000 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation angle | 73° |
| Calculated Volume (dm³) | 1.1321 |
| Color | Black |
| Distance between holes | 3.15 in |
| Exhaust | Hose Nozzle Ø 8.5 mm |
| Max. operating pressure | 145.0 psi |
| Mounting | M6 |
| Port thread 1 | M16 x 1.5 JED – 464 |
| Port thread 21 | M16 x 1.5 JED – 464 |
| Port threads | M16 x 1.5 VOSS |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057875296713 |
| Size (mm x mm x mm) | 178 x 106 x 60 |
| UPC | 193133369820 |
| Weight (kg) | 0.5 |
| Weight (lb) | 1.1023 |
| Brand | WABCO |
