Additional information
| Weight | 1,094 kg |
|---|---|
| Reference number | TDAS4613151610, S461-315-161-0, 2S4613151610, 2S461 315 161 0, 6300-4613151610, S4613151610, S461-315-161-0, WAB4613151610 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Basic valve | 4613150314 |
| Calculated Volume (dm³) | 1.1728 |
| Distance between holes | 2.4×2.4 in |
| Exhaust | Union |
| Max. operating pressure | 145.0 psi |
| Mounting | 4 Holes Ø 9 mm |
| Port thread 11 | 3/8" – 18 NPTF |
| Port thread 12 | 3/8" – 18 NPTF |
| Port thread 21 | 3/8" – 18 NPTF |
| Port thread 22 | 3/8" – 18 NPTF |
| Predominance | 4.35 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057875208808 |
| Size (mm x mm x mm) | 157 x 83 x 90 |
| UPC | 193133442165 |
| Weight (lb) | 2.4119 |
| Weight (kg) | 1.094 |
| Brand | WABCO |
