Additional information
| Weight | 1,18 kg |
|---|---|
| Reference number | A0034319505, A0034319705, 0034319505, A0034319505, 0034319705, A0034319705 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Basic valve | 4613150300 |
| Calculated Volume (dm³) | 1.152 |
| Comments | 11 and 21 are at 90° to 12 and 22 |
| Distance between holes | 2.4×2.4 in |
| Exhaust | Snap-on contour |
| Max. operating pressure | 145.0 psi |
| Mounting | 4 Holes Ø 9 mm |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Predominance | 2.90 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057875208594 |
| Size (mm x mm x mm) | 160 x 90 x 80 |
| Weight (kg) | 1.18 |
| Weight (lb) | 2.6015 |
| UPC | 193133302230 |
| Brand | WABCO |
