Additional information
| Weight | 1,294 kg |
|---|---|
| Reference number | 1522226, 3514010H0100, A0044314105, A0044314105, 1522226 |
| Brand | ProVia |
| Part type | Reliable spare parts |
| Product category | Device |
| Basic valve | 4619045502 |
| Calculated Volume (dm³) | 7.449 |
| Distance between holes | 2.4×2.4 in |
| Exhaust | Silencer |
| Max. operating pressure | 188.5 psi |
| Max. temporarily pressure | 188.55 psi |
| Mounting | 4x M8 |
| Operating pressure | 147.9 psi |
| Port thread 11 | M22 x 1.5 |
| Port thread 12 | M22 x 1.5 |
| Port thread 21 | M22 x 1.5 |
| Port thread 22 | M22 x 1.5 |
| Ports | M22 x 1.5 VOSS |
| Predominance | 7.25 psi |
| ProVia warranty | 1 year |
| Technical specification | AM specification |
| GTIN | 04057877003982 |
| Size (mm x mm x mm) | 252 x 177 x 167 |
| UPC | 193134004096 |
| Weight (kg) | 1.294 |
| Weight (lb) | 2.853 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
