Additional information
| Weight | 0,358 kg |
|---|---|
| Reference number | 6518472, 0691640, 691640, 1142040, 500002558, 0300632800, 500002558, 81521616205, 1695943, 1696230, 1696234, 81521616205, 1504927, 5000807916, 10559125, 40691640, 1695943, 1696230, 1696234, 81521616205 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Basic valve | 4613245200 |
| Calculated Volume (dm³) | 0.48268 |
| Comments | Starting pressure set at 0.3 bar, final pressure adjustable from 2.8 to 4.5 bar |
| Distance between holes | 2.52 in |
| Exhaust | Flap |
| Max. operating pressure | 145.0 psi |
| Mounting | 2x Ø 6.6 mm |
| Nominal diameter | 5.0 mm |
| Port thread 13 | M12 x 1.5 |
| Port thread 23 | M12 x 1.5 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Retarder Control |
| GTIN | 7895851006218 |
| Size (mm x mm x mm) | 114 x 73 x 58 |
| UPC | 193133304739 |
| Weight (lb) | 0.78925 |
| Weight (kg) | 0.358 |
| Brand | WABCO |
