Additional information
| Weight | 1,4 kg |
|---|---|
| Reference number | 1518069, A0034316305, 0034316305, 0034316405, 0034316505, 0034316805, A0034316305 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 1.8918 |
| Comments | 4 Studs M8x20. For voss push-in fittings |
| Distance between holes | 2.4×2.4 in |
| Exhaust | Union |
| Max. operating pressure | 145.0 psi |
| Mounting | 4x M8 |
| Port thread 11 | M22 x 1.5 |
| Port thread 12 | M22 x 1.5 |
| Port thread 21 | M22 x 1.5 |
| Port thread 22 | M22 x 1.5 |
| Port thread 3 | Union |
| Port thread 4 | M16x1.5 JED – 388 |
| Predominance | 5.80 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057875210467 |
| UPC | 193133304234 |
| Weight (kg) | 1.4 |
| Weight (lb) | 3.0865 |
| Size (mm x mm x mm) | 197 x 97 x 99 |
| Brand | WABCO |
