Additional information
| Weight | 3,374 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation | 4619077942 |
| Basic valve | 4613150731 |
| Calculated Volume (dm³) | 13.54 |
| Distance between holes | 3.15×7.09 in |
| Electrical connection | Bayonet plug 4-pin |
| Exhaust | Snap-on contour |
| Max. operating pressure | 145.0 psi |
| Mounting | 3x Ø 9.5 mm |
| Pedal angle | 43° |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057875210269 |
| UPC | 193133001003 |
| Weight (kg) | 3.374 |
| Weight (lb) | 7.438 |
| Size (mm x mm x mm) | 470 x 240 x 120 |
| Brand | WABCO |
