Additional information
| Weight | 3,367 kg |
|---|---|
| Reference number | 660687, TDAS4613186090, 6300-4613186090, S4613186090, 16L0008516AA, WAB4613186090 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation | 4619077942 |
| Basic valve | 4613154441 |
| Calculated Volume (dm³) | 11.6642 |
| Distance between holes | 3.15×7.09 in |
| Electrical connection | Bayonet plug 4-pin |
| Exhaust | Snap-on contour |
| Max. operating pressure | 145.0 psi |
| Mounting | 3x Ø 9.0 mm |
| Pedal angle | 45° |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057875210191 |
| UPC | 193133442264 |
| Weight (kg) | 3.367 |
| Weight (lb) | 7.423 |
| Size (mm x mm x mm) | 280 x 393 x 106 |
| Brand | WABCO |
