Additional information
| Weight | 3,374 kg |
|---|---|
| Reference number | W20705.03300.01W, 1518794, 6127GC-3514010, S3514010C17Z, 3514015862C01A, S3514010Z87C, 1612135500001, 1612035900003, 1,61214E+12, 35XA1-14020, 04775057, 4775057, W20705.03300.01W, 3514015-862-C01/A, S3514010-Z87C, 35XA114020, 235400040, 35XA1-14020, 1102407543908, 6180DB3514010, 6180DB-3514010, AZ87351400101, SWB563050036, 351400033, 3514-00033, 3514-10-00003 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation | 4613187942 |
| Basic valve | 4613154760 |
| Calculated Volume (dm³) | 12.5481 |
| Distance between holes | 3.15×7.09 in |
| Electrical connection | ITT Cannon 4-pin |
| Exhaust | Union |
| Max. operating pressure | 145.0 psi |
| Mounting | 3x Ø 9.0 mm |
| Pedal angle | 45° |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Predominance | 4.35 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Size (mm x mm x mm) | 386 x 258 x 126 |
| UPC | 193133303190 |
| Weight (kg) | 3.374 |
| Weight (lb) | 7.4384 |
| GTIN | 04057875209959 |
| Brand | WABCO |
