Additional information
| Weight | 2,531 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation | Yes |
| Basic valve | 4613150120 |
| Calculated Volume (dm³) | 8.6693 |
| Distance between bolts | 2.95×7.6 in |
| Exhaust | Flap |
| Max. operating pressure | 145.0 psi |
| Mounting | 4x Ø 9.5 mm |
| Pedal | Yes |
| Pedal angle | 45° |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 3 | Flap |
| Predominance | 4.35 psi |
| Technical specification | OE specification |
| GTIN | 04057875209546 |
| Size (mm x mm x mm) | 122 x 380 x 187 |
| UPC | 193133303329 |
| Weight (kg) | 2.531 |
| Weight (lb) | 5.5799 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
