Additional information
| Weight | 2,344 kg |
|---|---|
| Reference number | W20705.01500.11W, 6127AJ-3514010, S3514010-Z77, 1611135500002, 1,61114E+12, CK001-I-90020878, W20705.01500.11W, 35KA714020, 35KA7-14020, 6122F-3514010, SWB563050052, 3514-00005, 3514-10-00009, 3500-11-00041 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation | Yes |
| Basic valve | 4613150400 |
| Calculated Volume (dm³) | 8.1005 |
| Distance between bolts | 3.94×5.51 in |
| Exhaust | Flap |
| Max. operating pressure | 145.0 psi |
| Mounting | 3x M8 |
| Pedal | Yes |
| Pedal angle | 45° |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 3 | Flap |
| Predominance | 4.35 psi |
| Technical specification | OE specification |
| GTIN | 04057875209447 |
| Size (mm x mm x mm) | 358 x 187 x 121 |
| UPC | 193133303268 |
| Weight (kg) | 2.344 |
| Weight (lb) | 5.1676 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
