Additional information
| Weight | 2,488 kg |
|---|---|
| Reference number | 1506090, 1506090, 20215560, 215560 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation | Yes, 4613177902 |
| Basic valve | 4613150780 |
| Calculated Volume (dm³) | 9.282 |
| Distance between holes | 3.74×5.83 in |
| Exhaust | Silencer |
| Max. operating pressure | 145.0 psi |
| Mounting | 3x Ø 9.5 mm |
| Pedal | Yes |
| Pedal angle | 35° |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 3 | Silencer |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Size (mm x mm x mm) | 136 x 390 x 175 |
| UPC | 193133303312 |
| Weight (kg) | 2.488 |
| Weight (lb) | 5.4851 |
| GTIN | 04057875209324 |
| Brand | WABCO |
