Additional information
| Weight | 2,27 kg |
|---|---|
| Reference number | 1506089, 32405340, ACHA498, F00282558, 5660505, 0005660505, 8410146, 2089908, 32405340 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation | Yes, 4613177902 |
| Basic valve | 4613150040 |
| Calculated Volume (dm³) | 9.0148 |
| Exhaust | Union |
| Max. operating pressure | 145.0 psi |
| Mounting | 7x M8 |
| Pedal | Yes |
| Pedal angle | 35° |
| Port thread 11 | M16 x 1.5 + M12 x 1,5 |
| Port thread 12 | M16 x 1.5 + M12 x 1.23 |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 3 | Union |
| Predominance | 4.35 psi |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Size (mm x mm x mm) | 299 x 225 x 134 |
| UPC | 193133302704 |
| Weight (kg) | 2.27 |
| Weight (lb) | 5.0045 |
| GTIN | 04057875209416 |
| Brand | WABCO |
