Additional information
| Weight | 1,556 kg |
|---|---|
| Reference number | A0012604963, A0012602263, 0012602263, 0012604963, A0012602263, A0012604963, A0012602263, |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 2.6315 |
| Cooling | Air |
| Distance between holes | 3.31/5.04 in |
| Electrical connection | Bayonet DIN 72 585 A1-3.1-Sn/K2 |
| Max. operating pressure | 145.0 psi |
| Mounting | 2x Ø 11.5/2x Ø 13.5 |
| Port thread 14 | VOSS 230 NG8 |
| Port thread 35 | Ø 2.9 mm |
| Protection class | IP 69K / IP 67 |
| Rated current | 530 mA |
| System | EPS II |
| Technical specification | OE specification |
| Temperature range | -25°C to +120°C |
| Voltage | 24 V |
| GTIN | 04057875219606 |
| Size (mm x mm x mm) | 157 x 151 x 111 |
| Weight (kg) | 1.556 |
| Weight (lb) | 3.4304 |
| UPC | 193133312253 |
| Brand | WABCO |
