Additional information
| Weight | 2,26 kg |
|---|---|
| Reference number | 661657, 3425002880, 34250 02880, P34250 02880, 1343254, 2109009, 4C463038AA, 1618029600001, 81210554, MK471497, 559507K700, 55950 7K700, 41211013, 8015530, 8983319150, 41211013, 20707211, 5010422345, 81259026146, 81259026239, 81521606153, 29Y1145025, VS70000166, 505820513, ABRB811, 1343254, F00257376, 6300-4728800010, 81259026239, 2Z0607361G, 20707211, 41211013, 5010422345, 81259026146, 81521606153, 12-06-1162, S4728800010, 81259026239, 5010422345, 20707211, 41211013, 81259026146, 81259026239, 81521606153, 1934983, 1448079, 1023612, 6180J3629113, 759000177, 41343254, 28220102600, 20707211, 41211013, 5010422345, 81259026146, 81259026239, 81521606153, WAB4728800010, 2Z0607361F, 350601075 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 2.627 |
| Electrical connection | Bayonet DIN 72585-A1-4.1-Sn/K2 |
| Max. operating pressure | 290.1 psi |
| Mounting | 2 x Ø 9 mm |
| Multi Nominal diameter (From Port 1 to x) | 0.39 / 0.28 in |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port thread 21 | M22 x 1.5 JED – 388 |
| Port thread 22 | M22 x 1.5 JED – 388 |
| Port thread 23 | M22 x 1.5 JED – 388 |
| Port thread 3 | Silencer 432 407 060 0 |
| Protection class | IP 6K9K / IP 6K6K |
| Rated current | 320 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 24 V |
| GTIN | 7895851051966 |
| UPC | 193133443957 |
| Weight (kg) | 2.26 |
| Weight (lb) | 4.982 |
| Size (mm x mm x mm) | 207 x 167 x 76 |
| Brand | WABCO |
