Additional information
| Weight | 4,892 kg |
|---|---|
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 4.634 |
| Electrical connection | Bayonet DIN 72585-A1-4.1-Sn/K2, Bayonet DIN 72585-A1-4.1-Sn/K2 |
| Max. operating pressure | 290.1 psi |
| Mounting | 2 x M8 |
| Multi Nominal diameter (From Port 1 to x) | 0.39 / 0.28 in |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port thread 21 | M22 x 1.5 JED – 388 |
| Port thread 22 | M22 x 1.5 JED – 388 |
| Port thread 23 | M22 x 1.5 JED – 388 |
| Port thread 25 | M22 x 1.5 JED-388 |
| Port thread 26 | M22 x 1.5 JED-388 |
| Port thread 27 | M22 x 1.5 JED-388 |
| Port thread 3 | Silencer 432 407 060 0 |
| Protection class | IP 6K9K |
| Rated current | 320 mA |
| Technical specification | OE specification |
| Voltage | 24 V |
| GTIN | 04057875220381 |
| Size (mm x mm x mm) | 205 x 137 x 165 |
| UPC | Z5 |
| Weight (kg) | 4.892 |
| Weight (lb) | 10.785 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
