Additional information
| Weight | 4,366 kg |
|---|---|
| Reference number | 1506654, 7082787, 46030, 1015374, 5311-056, GB42000430, 6BE00080200, 167733, 35260, GB42000430, VS70000141, 5816896, 58168960, 505816896, 21150110035, 349975, 2349975, 3499750, 1237710, 10167581, A05101365, 6300-4801020140, N2509990144, A6000JC11480, 910015-00053, 1955975, 400261015, AIF1166, 1506654, 5021170240, 4801020140, 1738466, 1802089, 056662, 56662, INS0160106, 1182102, 54788, 21150110035, T423-001, 10868344, 45010804, WA4801020140, WAB4801020140, 1043057 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 15.1939 |
| Distance between bolts | 5.31 in |
| Electrical connection | Bat/ILS/ECAS/ELM/24N/Telematik |
| Max. operating pressure | 123.3 psi |
| Mounting | 2x M10 mm |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | M22 x 1.5 |
| Port thread 22 | M22 x 1.5 |
| Port thread 3 | 2 Integrated Silencer |
| Port thread 4 | M16 x 1.5 |
| Port thread 5 | M16 x 1.5 |
| Protection class | IP 66 |
| System | 4S/3M |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Type | Premium |
| Voltage | 24 V |
| GTIN | 7895851043541 |
| Packaging size (mm x mm x mm) | 360 x 210 x 192 |
| Packaging volume (dm³) | 14.52 |
| Size (mm x mm x mm) | 304 x 210 x 238 |
| UPC | 193133444794 |
| Weight (kg) | 4.366 |
| Weight (lb) | 9.6254 |
| Version | TEBS D |
| Brand | WABCO |
