Additional information
| Weight | 4,4 kg |
|---|---|
| Reference number | 7121723, 151865, 151856, 5311-069, 170878, GB42000800, S480-102-060-0, VS70000254, S4801020600, A3000JC15900, 924301-00109, 3330333, 905815, S480-102-060-0, 1935125, 1103984, T423-039 |
| Brand | ZF REMAN – WABCO |
| Part type | Remanufactured |
| Product category | Device |
| Calculated Volume (dm³) | 8.87 |
| Distance between bolts | 2.76 in |
| Important information | Please purchase Kit 4615139202 for proper installation when replacing a modulator with PEM. |
| Max. operating pressure | 123.28 psi |
| Mounting | 2x M12 |
| Port thread 1 | M22 x 1.5 JED-152 |
| Port thread 21 | M16 x 1.5 JED – 152 |
| Port thread 22 | M16 x 1.5 JED – 152 |
| Port thread 3 | 2 Integrated Silencer |
| Port thread 4 | M16 x 1.5 JED – 152 |
| Port thread 5 | M16 x 1.5 JED-152 |
| Protection class | IP 6K9K |
| System | 4S/3M |
| Technical specification | OE specification |
| Temperature range | 40°F to 149°F |
| Type | Premium |
| Voltage | 24 V |
| GTIN | 04057885319419 |
| Size (mm x mm x mm) | 224 x 200 x 198 |
| UPC | 193133532460 |
| Weight (kg) | 4.4 |
| Weight (lb) | 9.7 |
| Version | TEBS E without PEM |
| Brand | WABCO |
