Additional information
| Weight | 6,3 kg |
|---|---|
| Reference number | 515027404 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 35.494 |
| Distance between bolts | 2.76 in |
| Max. operating pressure | 123.28 psi |
| Mounting | 2x M12 |
| Port thread 1 | 15 x 1.5 / 10 x 1 |
| Port thread 11 | 8 x 1 / 8 x 1 |
| Port thread 21 | 12 x 1.5 |
| Port thread 22 | 12 x 1.5 |
| Port thread 23 | 8 x 1 |
| Port thread 24 | 8 x 1 |
| Port thread 3 | 2 Integrated Silencer |
| Port thread 4 | 8 x 1 |
| Port thread 5 | 8 x 1 |
| Protection class | IP 6K9K |
| System | 4S/3M |
| Technical specification | OE specification |
| Type | Premium |
| Version | TEBS E with PEM |
| Voltage | 24 V |
| GTIN | 04057875228837 |
| Size (mm x mm x mm) | 224 x 270 x 198 |
| UPC | 193133317180 |
| Weight (kg) | 6.3 |
| Weight (lb) | 13.89 |
| Temperature range | -40°C to +65°C |
| Brand | WABCO |
