Additional information
| Weight | 7,02 kg |
|---|---|
| Reference number | 7118837, 1066116, 170974, 515024036, 21150110185, 1268388, AIF2062, 1935126, 1042743, 1115125, 83603, 21150110185, 11074055 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 11.49 |
| Distance between bolts | 2.76 in |
| Max. operating pressure | 123.28 psi |
| Mounting | 2x M12 |
| Port thread 1 | 15 x 1.5 / 8 x 1 |
| Port thread 11 | 12 x 1.5 / 8 x 1 |
| Port thread 21 | 12 x 1.5 |
| Port thread 22 | 12 x 1.5 |
| Port thread 23 | 8 x 1 |
| Port thread 24 | 8 x 1 |
| Port thread 3 | 2 Integrated Silencer |
| Port thread 4 | 8 x 1 |
| Port thread 42 | 8 x 1 |
| Port thread 5 | 8 x 1 |
| Protection class | IP 6K9K |
| System | 4S/3M |
| Temperature range | -40°C to +65°C |
| Type | Premium |
| Version | TEBS E with PEM |
| Voltage | 24 V |
| GTIN | 04057875228790 |
| Size (mm x mm x mm) | 224 x 259 x 198 |
| UPC | 193133317197 |
| Weight (kg) | 7.022 |
| Weight (lb) | 15.48 |
| Technical specification | OE specification |
| Brand | WABCO |
