Additional information
| Weight | 3,5 kg |
|---|---|
| Reference number | 81521306287, 81521306306, 81521306307, 81521306308, 81521306309, 81521306310 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 4.3358 |
| Distance between holes | 3.31×1.26 in |
| Max. operating pressure | 184.20 psi |
| Mounting | 4 x M8 |
| Port thread 11 | M22 x 1.5 JED – 388-4 |
| Port thread 12 | M22 x 1.5 JED – 388-4 |
| Port thread 21 | M22 x 1.5 JED – 388-4 |
| Port thread 22 | M22 x 1.5 JED – 388-4 |
| Port thread 23 | M16 x 1.5 JED – 388-4 |
| Protection class | IP 6K6K / IP 6K9K |
| System | 4S/3M, 4S/4M, 6S/6M |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Version | HA60_CAB |
| Voltage | 24 V |
| GTIN | 04057875228608 |
| Weight (kg) | 3.5 |
| Weight (lb) | 7.7162 |
| Size (mm x mm x mm) | 282 x 123 x 125 |
| Brand | WABCO |
