Additional information
| Weight | 6,29 kg |
|---|---|
| Reference number | DP002148, 1505278, A0004291524, 4291524, 4292124, A0004292124, 4290324, 4290624, 4290824, 1505278, 1935128 |
| Brand | ZF REMAN – WABCO |
| Part type | Remanufactured |
| Product category | Device |
| Application | 2-Axle vehicles |
| Calculated Volume (dm³) | 12.6 |
| Comments | AXOR,ATEGO/S (EPB-paket 99) |
| Distance between holes | 3.94 in |
| Electrical connection | Bayonet DIN 72585 1A-4.1-Sn/K2 |
| Max. operating pressure | 145.0 psi |
| Mounting | 2x M12 x 1.5 |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port thread 12 | M22 x 1.5 JED – 388 |
| Port thread 13 | M22 x 1.5 JED-388 |
| Port thread 21 | M22 x 1.5 JED – 388 |
| Port thread 22 | M22 x 1.5 JED – 388 |
| Port thread 23 | M16 x 1.5 JED – 388 |
| Port thread 3 | Integrated Silencer |
| Protection class | IP 66 / IP 69 K |
| Rated current | 5 A |
| Temperature range | -40°C to +80°C |
| Type | 4 x 2 |
| Voltage | 24 V |
| GTIN | 04057875632016 |
| Size (mm x mm x mm) | 350 x 200 x 180 |
| UPC | 193133317494 |
| Weight (kg) | 6.288 |
| Weight (lb) | 13.86 |
| Technical specification | OE specification |
| Brand | WABCO |
