Additional information
| Weight | 6,28 kg |
|---|---|
| Reference number | 1505279, A0004292224, A0004291624, A0004292224, A00042916240085, 4291624, 4292224, 42916240085, 4290424, 4290724, 4290924, 930624103701, 1505279 |
| Brand | ZF REMAN – WABCO |
| Part type | Remanufactured |
| Product category | Device |
| Application | 6×2, 6×4, 8×4, 6×2/4 |
| Calculated Volume (dm³) | 12.96 |
| Distance between holes | 3.94 in |
| Electrical connection | Bayonet DIN 72585 1A-4.1-Sn/K2 |
| Max. operating pressure | 145.0 psi |
| Mounting | 2x M12 x 1.5 |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port thread 12 | M22 x 1.5 JED – 388 |
| Port thread 13 | M22 x 1.5 JED-388 |
| Port thread 21 | M22 x 1.5 JED – 388 |
| Port thread 22 | M22 x 1.5 JED – 388 |
| Port thread 23 | M16 x 1.5 JED – 388 |
| Port thread 3 | Integrated Silencer |
| Protection class | IP 66 / IP 69 K |
| Rated current | 5 A |
| Technical specification | OE specification |
| Type | 6 x 2, 6 x 2/4, 6 x 4, 8 x 4 |
| Voltage | 24 V |
| GTIN | 04057875615170 |
| Size (mm x mm x mm) | 360 x 200 x 180 |
| UPC | 193133317487 |
| Weight (kg) | 6.28 |
| Weight (lb) | 13.85 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
