Additional information
| Weight | 3,093 kg |
|---|---|
| Reference number | 1867002, S480-106-105-0, S4801061050, S480-106-105-0 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 5.6587 |
| Distance between holes | 3.94 in |
| Max. operating pressure | 188.5 psi |
| Mounting | 2x M12 x 1.5 |
| Port thread 11 | M22 x 1.5 JED – 388-4 |
| Port thread 12 | M22 x 1.5 JED – 388-4 |
| Port thread 21 | M22 x 1.5 JED – 388-4 |
| Port thread 22 | M22 x 1.5 JED – 388-4 |
| Port thread 3 | Integrated Silencer |
| Port thread 4 | M16 x 1.5 JED – 388-4 |
| Protection class | IP 6K6K / IP 6K9K |
| Rated current | 7 A |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 24 V |
| GTIN | 04057875229377 |
| UPC | 193133444848 |
| Weight (kg) | 3.093 |
| Weight (lb) | 6.8189 |
| Size (mm x mm x mm) | 227 x 164 x 152 |
| Brand | WABCO |
