Additional information
| Weight | 5,909 kg |
|---|---|
| Reference number | 9500960, 0004292024, 0004292724, A0004292724, A0004292024, 9500960 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Application | 6×2, MP II |
| Calculated Volume (dm³) | 8.5239 |
| Distance between holes | 3.94 in |
| Electrical connection | Bayonet DIN 72585 1A-4.1-Sn/K2 |
| Max. operating pressure | 145.0 psi |
| Mounting | 2x M12 x 1.5 |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port thread 12 | M22 x 1.5 JED – 388 |
| Port thread 13 | M22 x 1.5 JED-388 |
| Port thread 21 | M22 x 1.5 JED – 388 |
| Port thread 22 | M22 x 1.5 JED – 388 |
| Port thread 23 | M16 x 1.5 JED – 388 |
| Port thread 3 | Integrated Silencer |
| Protection class | IP 66 / IP 69 K |
| Rated current | 5 A |
| Technical specification | OE specification |
| Type | All vehicles except 4 x 2 |
| Voltage | 24 V |
| GTIN | 7895851044142 |
| Size (mm x mm x mm) | 231 x 205 x 180 |
| UPC | 193133317616 |
| Weight (kg) | 5.909 |
| Weight (lb) | 13.027 |
| Temperature range | -40°C to +80°C |
| Brand | WABCO |
