Additional information
| Weight | 5,878 kg |
|---|---|
| Reference number | A0004292324, N1011066338, 0004292324, A0004292324, 1102732000 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Application | ZA OHNE REDUNDANZ |
| Calculated Volume (dm³) | 8.1982 |
| Comments | 500 Kba NICHT ABWAERTSKOMPATIBEL |
| Distance between holes | 3.94 in |
| Electrical connection | Bayonet DIN 72585 1A-4.1-Sn/K2 |
| Important information | Learn more about the core return process (<a href="https://www.wabco-customercentre.com/solutioncentre/s/article/Return-the-core-get-your-money-back?language=en_US" target="_blank">Click here</a> ) |
| Max. operating pressure | 145.0 psi |
| Mounting | 2x M12 x 1.5 |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port thread 12 | M22 x 1.5 JED – 388 |
| Port thread 13 | M22 x 1.5 JED-388 |
| Port thread 21 | M22 x 1.5 JED – 388 |
| Port thread 22 | M22 x 1.5 JED – 388 |
| Port thread 23 | M16 x 1.5 JED – 388 |
| Port thread 3 | Integrated Silencer |
| Protection class | IP 66 / IP 69 K |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Drive axle 4 × 2 with backup valve |
| Voltage | 24 V |
| GTIN | 04057875229193 |
| Size (mm x mm x mm) | 229 x 179 x 200 |
| UPC | 193133316978 |
| Weight (kg) | 5.878 |
| Weight (lb) | 12.959 |
| Rated current | 5 A |
| Brand | WABCO |
