Additional information
| Weight | 5,895 kg |
|---|---|
| Reference number | 1315705, 871491, 0871491, 1315705, 1315705, 1935132 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Application | 4×2, 6×4, 6×2/4 |
| Calculated Volume (dm³) | 8.1624 |
| Distance between holes | 3.94 in |
| Electrical connection | Bayonet DIN 72585 1A-4.1-Sn/K2 |
| Important information | Learn more about the core return process (<a href="https://www.wabco-customercentre.com/solutioncentre/s/article/Return-the-core-get-your-money-back?language=en_US" target="_blank">Click here</a> ) |
| Max. operating pressure | 145.0 psi |
| Mounting | 2x M12 x 1.5 |
| Port thread 11 | M22 x 1.5 JED – 388 |
| Port thread 12 | M22 x 1.5 JED – 388 |
| Port thread 13 | M22 x 1.5 JED-388 |
| Port thread 21 | M22 x 1.5 JED – 388 |
| Port thread 22 | M22 x 1.5 JED – 388 |
| Port thread 23 | M16 x 1.5 JED – 388 |
| Port thread 3 | Integrated Silencer |
| Protection class | IP 66 / IP 69 K |
| Rated current | 5 A |
| Temperature range | -40°C to +80°C |
| Type | 6 × 2 with backup valve |
| Voltage | 24 V |
| GTIN | 04057875229094 |
| Size (mm x mm x mm) | 228 x 179 x 200 |
| UPC | 193133317227 |
| Weight (kg) | 5.895 |
| Weight (lb) | 12.996 |
| Technical specification | OE specification |
| Brand | WABCO |
