Additional information
| Weight | 8,228 kg |
|---|---|
| Reference number | 1474663, 1535829, 1753577, 1738295, 1770184, 1928589, 1796161, 1941953, 2148069, 2063357, 2308777, 1543224, 1763425, 1897631, 2089579 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 33.744 |
| Closing pressure static 21 | 65.3 psi |
| Closing pressure static 22 | 65.3 psi |
| Closing pressure static 23 | 65.3 psi |
| Closing pressure static 24 | 65.3 psi |
| Electrical connection | DIN 72585 A1-2.1-1-Sn/K2 |
| Max. operating pressure | 181.3 psi |
| Opening pressure 21 | 108.78 psi |
| Opening pressure 22 | 108.78 psi |
| Opening pressure 23 | 104.43 psi |
| Opening pressure 24 | 108.78 psi |
| Opening pressure 25 | 123.28 psi |
| Port thread 12 | M12 x 1.5 |
| Port thread 24 | M12 x 1.5 |
| Port thread 4 | M12 x 1.5 |
| Technical specification | OE specification |
| Voltage | 24 V |
| GTIN | 7895851081338 |
| Size (mm x mm x mm) | 370 x 240 x 380 |
| UPC | 193133361008 |
| Weight (kg) | 8.228 |
| Weight (lb) | 18.14 |
| Temperature range | -40°F to +149°F |
| Brand | WABCO |
